4 Pass Thermic Fluid Heater

Get a Price/Quote

Product Details:

Type 4 Pass Thermic Fluid Heater
Material Metal
Color Silver
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

4 Pass Thermic Fluid Heater Price And Quantity

Minimum Order Quantity 1 Unit

4 Pass Thermic Fluid Heater Product Specifications

Color Silver
Type 4 Pass Thermic Fluid Heater
Material Metal

4 Pass Thermic Fluid Heater Trade Information

Supply Ability 10 Unit Per Month
Delivery Time 10-15 Days
Main Domestic Market All India

Product Description

6 LACS - Kcal/ Hours to 90 lacs - kcal/ Hour With Solid Fuel Firing

We are engaged in offering 4 Pass Thermic Fluid Heaters to our clients all over the world. These are available in different capacities as well as various specifications to suit the exact requirements of the clients. Equipped with fluid pipelines, storage tanks etc. these can be easily installed. We provide these at the most competitive prices.

We are one of the preeminent manufacturers and exporters of Thermic Fluid Heaters in the market. We are able to offer Thermic Fluid Heaters, which are energy efficient and work on liquid & vapor phase. Known for longer working life, these can be used with gas, oil, coal and agro-waste fuels. Our precision engineered Thermic Fluid heaters are robust in construction and require less maintenance costs as compared to conventional heaters. We offer Thermic Fluid Heaters in a variety of sizes and can also customize them according to the client.

Characteristics

4 Pass Design Multi Start Coil
Split Design/Parallel Design
Higher Heat transfer Area Of 9 to 10 Square Meter Per 1 lac Kcal/hour his Provided
Multi fuel Option
FBC Automatic Fuel feeding System
Long thermic fluid life
Corrosion free
No scale problems
No boiler regulation
High temperature
Abrasion resistant
Easy to use

Consists of

Radiant & Convective Coil Heat Exchanger.
Shell for Enclosing Coil Assembly.
Air Preheater
Multi Cyclone Dust Collector or
Treema Cyclone-Cyclomax. or
Wet Scrubber.
Furnace with Fire Doors & Ash Doors.
Fire Bars or Air Nozzel Box.
Screw Feeder. Expansion Cum Deaerator Tank
High temperature re-circulating pumps
Advanced safety features
Complete control panel

Specifications

Abnormal Condition	Safety Action
Low Thermic Fluid Level in Expansion Tank	Level Switch actuated at expansion tank cuts of the ID Fan / FD Fan.

Low Thermic Fluid Flow	Differential pressure switch (DPS) across inlet and outlet headers cuts of the ID Fan slowing down combustion

Thermic Fluid system pressure high due to system valves closure etc.	Pressure switch cuts of ID Fan and alarm. Safety relief valve (Optional) to be provided in the system piping so as to by pass the oil.

Thermic Fluid Temperature High	Digital Temperature cuts of ID fan at set point

Coil Chocking	Differential pressure Switch (DPS) across system cuts of the ID Fan Slowing down combustion

Thermic Fluid Motor Trip	Electrical Interlock cuts of fans

Power Failure	Diesel Engine (Optional) keeps thermic fluid moving to avoid overheating and overflow of oil. Exhaust with Damper provided on furnace to drive away hot gases directly.
